40ft High Cube Modified Shipping Container with Man Door and Roll Up Door

A 40ft high cube modified shipping container with man door and roll up door combines the security and durability of a Corten steel container with convenient personnel access and wide cargo entry, making it ideal for workshops, garages, site storage, and retail applications . This modified unit is perfect for businesses needing both everyday walk-in access for staff and oversized entry for equipment, pallets, or vehicles. Unlike standard containers with double doors only, this unit features a standard 36-inch steel man door (personnel access) plus a wide roll-up door (typically 8ft-10ft wide) for larger items . As a result, you receive a versatile, weatherproof workspace that eliminates the need to open heavy cargo doors for routine access. Learn about container modifications from official HSE guidelines.

Why Choose a Man Door and Roll Up Door Configuration?

Standard containers require opening heavy double doors for every entry. In contrast, this unit’s man door provides convenient daily access for staff, while the roll up door handles larger cargo when needed . Consequently, the 40ft high cube dimensions (9ft 6in exterior, approx. 8ft 10in interior height) provide ample space for storage or workshop activities. Moreover, the roll-up door operates smoothly on galvanised steel tracks with spring-assisted mechanism . Thus, you gain both convenience and functionality in a single modified container.

Key Features of This Modified Container

The man door and roll-up door configuration are the defining features of this unit. The steel man door (typically 36 inches wide x 80 inches high) features a heavy-duty three-point locking system (top, bottom, side) with internal and external handles, plus a deadbolt for security . The roll-up door (typically 8ft-10ft wide x 8ft high) is constructed from galvanised steel slats, operates on ball-bearing rollers, and includes a locking mechanism . The Corten steel construction provides corrosion resistance, while the high cube height offers standing headroom throughout. The CSC safety plate remains valid, allowing intermodal shipping if required . Double doors at the opposite end can be retained or removed depending on configuration .

Man Door and Roll Up Door Placement Options

The placement of doors can be customised to suit your workflow. For example, the man door is typically fitted on the side wall near one end for easy personnel access. The roll up door is commonly fitted on the side wall (creating a garage-style opening) or on the end wall (replacing or supplementing standard double doors). If you need drive-through access, doors can be fitted on opposite sides. For maximum flexibility, retain the original double doors at one end and add both side doors.

Roll Up Door Specifications

The roll-up door is purpose-built for modified containers. The door is constructed from galvanised or powder-coated steel slats (typically 2 inches thick) that roll up into a compact coil above the opening. The galvanised steel tracks and ball-bearing rollers ensure smooth operation with a manual chain hoist (standard) or optional electric motor . The door includes a locking mechanism (typically slide bolts or hasps) for security. The rubber weather seals prevent dust and moisture ingress. The header design transfers wind load into the container structure, maintaining CSC integrity .

High Cube Height Advantage

The high cube height (9ft 6in exterior) provides significant advantages for modified containers. The internal height of approximately 8ft 10in (2,695mm) allows standing headroom for tall users, vertical pallet racking, and clearance for roll-up door operation . If you are converting the container into a workshop, office, or garage, the extra foot of height makes the space feel more open and functional. Standard height containers (8ft 6in exterior, 7ft 10in interior) cannot accommodate the same roll-up door header clearance.

What’s Included

First, every unit includes the 40ft high cube Corten steel container (used or one-trip condition) . Second, steel man door (36″ x 80″) with three-point locking system, internal/external handles, and deadbolt . Third, roll-up door (8ft-10ft wide x 8ft high) with galvanised steel slats, tracks, rollers, chain hoist, and locking mechanism . Fourth, rubber weather seals on both doors . Finally, CSC safety plate (valid) and lifting points (forklift pockets and crane lugs) for repositioning.

For instance, add an electric motor for automated roll-up door operation . Likewise, add windows, insulation, electrical fit-out, or a full repainting service. Contact our container team for custom configurations.

Pros and Cons

Pros:

• Steel man door (36″ x 80″) with three-point locking (convenient daily access)

• Roll-up door (8ft-10ft wide x 8ft high) for cargo/vehicle access

• High cube height (9ft 6in exterior, approx. 8ft 10in internal – standing headroom)

• Corten steel construction (weathering, corrosion-resistant)

• CSC certified (valid for intermodal shipping if required)

• Rubber weather seals on both doors (prevents dust/water ingress)

• Retain original double doors (optional – opposite end)

• Ideal for workshops, garages, retail, site storage

Cons:

• Modifications add cost over standard container

• Roll-up door reduces internal clear height near opening

• Significant delivery space required (110ft straight line clearance)

Technical Specifications

Final Verdict

In summary, this modified container delivers the perfect balance of everyday personnel access and wide cargo entry for versatile workspace applications. As a result, businesses can eliminate the inconvenience of handling heavy double doors for routine access while retaining the ability to load large items through the roll-up door. Consequently, one workshop owner replaced their standard container with this man door/roll-up door configuration, saving significant time on daily entries. Therefore, choose this modification if you need both personnel and cargo access in a single container. If you need a smaller footprint, consider our 20ft version. If you require a full drive-through configuration, add a second roll-up door at the opposite end. Thus, request a free quote with your preferred door sizes and placement today. Return to our modified container home page for other configurations and modifications.
